300Mbps Wireless N Range Extender

  • - One-touch for Easy Wireless Network Extension
    - 300Mbps Wi-Fi Speed
    - Stable Wireless Connection
    - Compatible with All 802.11b/g/n Devices
    - Advanced Security

  • EX302 is a  wireless range extender designed to expand your existing wireless network signals and coverage. You can extend  home Wi-Fi network simply by pressing the WPS button on device and router. So that more Wi-Fi devices can access Internet simultaneously, such as iPads, iPods, Notebooks, Smart Phones, Game Consoles and TV. With two antennas, EX302 ensures high transfer rate with stable signal.

    One-touch for Easy Wireless Network Extension
    Simply press the WPS button on both EX302 and wireless router, secure home Wi-Fi connection can be established quickly to extend the coverage of your existing Wi-Fi network.


    300Mbps Wi-Fi Speed
    Complying with 802.11n standard and delivers Wi-Fi speed up to 300Mbps, satisfying all internet activities like network commnication, online gaming and video streaming.


    Stable Wireless Connection
    Two high performance antennas ensurs stable Wi-Fi connection and high speed Internet access.


    Compatible with All 802.11b/g/n Devices
    EX302 is fully compatible with all 802.11b/g/n devices, including routers, access points, LAN cards etc.


    Advanced Security
    The most advanced WPA/WPA2 (TKIP/AES) encryption is provided to secure Wi-Fi connection and avoid any unauthorized use.

    - Complies with IEEE 802.11n /g/b standards for 2.4GHz Wireless LAN.
    - Up to 300Mbps data rate for Wi-Fi network.
    - Two external antennas enhance the throughput’s stability.
    - Allows more users to share one account to access Internet.
    - WPS push button for easy Wi-Fi network extension.
    - Power ON/OFF button is easy for power controlling.
    Interface  1 *10/100BaseTX (Auto MDI/MDIX) RJ45 port
    Power Supply  9V/0.5A (Passive POE)
    Antenna  2 *5dBi fixed antennas
    Button  1 *RST/WPS Button, 1 *Power ON/OFF
    LED Indicators  1 *Power, 1 *SYS, 1*Wi-Fi, 1*LAN, 1*LINK
    Dimensions (L x W x H)  5.8 x 3.0 x 1.0 in. ( 147.5 x 76 x 25 mm)
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    RF Frequency  2.4~2.4835GHz
    Data Rate  802. 11n: Up to 300Mbps
      802.11g: Up to 54Mbps (dynamic)
      802.11b: Up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
    EIRP  < 20dBm
    Reception Sensitivity  270M: -61 dBm@10% PER
      135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    Package Contents  EX302 Wireless Extender *1
      Power Adapter*1
      Ethernet Cable *1
      Quick Installation Guide *1
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
