AC4300 Wireless Tri-Band Gigabit Router

  • - 4266Mbps Super-high Speed Wi-Fi
    - Powerful CPU
    - Gigabit WAN and LAN Ports
    - USB3.0 Port
    - Eight High-gain Antennas
    - Wave2 MU-MIMO and Beamforming technology
    - Support IPTV
    - Support IPv6
  • A8000RU is AC4300 Wireless Tri-band Gigabit Router which complies with the latest IEEE802.11ac Wave 2 standards and delivers wireless speed up to 4266Mbps. MU-MIMO and Beamforming+ technologies ensure a stable wireless connection to the Internet for multiple devices at the same time. 5GHz Wi-Fi provides a blazing-fast, lag-free Wi-Fi experience for gaming, video streaming or surfing. A8000RU is equipped with eight external 5dBi omni-directional antennas and PA+LNA wireless signal amplification module, extending Wi-Fi over larger areas. Meanwhile , it supports the VPN , QoS, IPV6, IPTV etc , giving users the best Wi-Fi experience !
    4266Mbps Super-high Speed Wi-Fi
    1733Mbps on 5GHz(1) and 1733Mbps on 5GHz(2), offers super fast Wi-Fi for Gaming, Video and Download.
    800Mbps on 2.4GHz, offers wider wireless coverage as well as strong wall-through ability.
    Powerful CPU
    A8000RU adopts CA53 ARM 1.35G dual Core CPU, which offers a much higher working efficiency than the regular router and an outstanding ability on the data processing.
    Gigabit WAN and LAN Ports
    Equipped with full gigabit ports, A8000RU offers a larger capability for data streaming via cable connection, making the best use of your Internet bandwidth, and compatible with your 100M/1000M network card.
    USB3.0 Port
    Equipped with USB 3.0 port, it supports to share files based on the functions of FTP, Samba , Comparing with USB 2.0, USB 3.0 offers a much faster transmitting rate. And the USB port also supports to supply power to the connected device.
    Eight High-gain Antennas
    A8000RU is equipped with 4 high-gain 5G antennas and 4 dual-band(2.4G/5G) antennas, offering a super-fast, lag-free Wi-Fi experience for gaming, video streaming, as well as extending Wi-Fi over larger areas.

    Wave2 MU-MIMO and Beamforming technology
    With the latest Wave2 MU-MIMO and Beamforming technology, A8000RU supports to communicate with multiple devices at the same time and supports to transmit the signal to the wireless connected devices intensively, such as smart phones, tablets and laptops, thus improving the bandwidth efficiency and the Wi-Fi experience.
    Support IPTV
    With top-level configurations on hardware, A8000RU supports much powerful applications on firmware. IPTV is one of the most useful features for the users, which brings very good experience on Wi-Fi and Multi-media.
    Support IPv6
    Contrasting with other traditional routers, A8000RU has an advantage on its IPv6(PPPoE/DHCP/Static IP). A router supports IPv6 would be more compatible with the future Internet access.
    VPN Support
    VPN function is a very useful function on A8000RU, especially for the business people when on their trips. It helps to relocate the IP address to visit websites.
    APP Management
    With the latest TOTOLINK APP in hand, managing routers has never been so easier. From the base setup to advanced personal settings, users can access and configure the router anywhere and anytime on their smartphone. Meanwhile, the simple and intuitive interface on the APP enable the users better understanding their devices and networking status.

    - Tri-Band technology creates three separated Wi-Fi bands for more devices’ connections without degrading the Wi-Fi network performance.
    - Simultaneous 800Mbps on 2.4GHz, 1733Mbps on 5GHz(1) and 1733Mbps on 5GHz(2), totaling 4266Mbps bandwidth.
    - 1.35GHz Dual-Core CPU and three co-processors perform outstanding ability in data-processing without any delay.
    - Full gigabit WAN port and LAN ports  support  large data streaming via cable connection.
    - USB3.0 supports to share files based on the functions of FTP, Samba.
    - Eight high-gain antennas improve the sensitivity of signal transmission and reception.
    - Beamforming technology supports directional signal transmission and reception, reducing interference.
    - MU-MIMO technology supports simultaneous communications with multiple devices, reducing network latency.
    - Supports DHCP, Static IP, PPPoE, PPTP and L2TP Internet connection type.
    - QoS: Bandwidth Control based on IP address.
    - Supports Multiple SSIDs, WPS and Wireless Scheduler.
    - Supports  WPA/WPA2 MIX.
    - APP Management



    - 4 * 1000Mbps LAN Ports

    - 1 * 1000Mbps WAN Port

    - 1* Power Port

    - 1* USB 3.0 Port

    Power Supply

    - 12 VDC / 3.5A


    - 1 * RST Button

    - 1* WPS Button

    - 1* Power Button

    LED Indicator


    - 1 * SYSTEM  LED

    - 1* WAN LED

    - 4* LAN LED


    - 8* external detachable antennas(4* 5G antennas + 4* 2.4G/5G antennas)

    Dimensions (L x W x H) - 324mm x 203mm x 52.8mm (not concluding antennas)




    - IEEE 802.11ac,

    - IEEE 802.11a,

    - IEEE 802.11b,

    - IEEE 802.11g ,

    - IEEE 802.11n

    RF Frequency

    - 2.4GHz/5GH

    Data Rate

    - 2.4GHz: Up to 800Mbps

    - 5GHz: Up to 1733Mbps

    - 5GHz-1: Up to 1733Mbps


    - 2.4GHz < 20dBm

    - 5GHz < 20dBm

    Wireless Security 64/128-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK.
    Reception Sensiticity

    2.4G:11b 11M:-81dBm@8% PER

            11g 54M:-68dBm@10% PER

            11n HT20 MCS7:-65dBm@10% PER

                   HT40 MCS7:-62dBm@10% PER


     5G: 11a 54M:-68dBm@10% PER

           11n HT20 MCS7:-65dBm@10% PER

                  HT40 MCS7:-62dBm@10% PER

           11ac VHT80 MCS9:-51dBm@10% PER





    Menu - Description

    System Status

    - WAN

    - 5GHz Wireless

    - Traffic Statistics

    - LAN

    - 2.4GHz Wireless

    - System Information

    One Key Set

    - Connection Type

    - Wireless Setting


    - Connection Status

    - Connection Type

    - Advance Settings


    - IP Address

    - Subnet Mask

    - DHCP Server

    - DHCP Start IP Address

    - DHCP End IP Address


    - 2.4G Wireless

    - 5G Wireless

    - 5G_1 Wireless



    Package Contents

    - A8000RU Wireless Router *1

    - Power Adapter *1

    - Ethernet Cable *1

    - Quick Installation Guide *1


    - Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)

    - Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)

    - Operating Humidity: 10%~90% non-condensing

    - Storage Humidity: 5%~90% non-condensing
