N301RT

300Mbps Wireless N Router

  • - Wireless N Speed
    - Stable Performance
    - Enjoy Your IPTV
    - Easy Setup
    - Multiple Networks Available
    - Advanced Security
    - Parental Control
    - IPv6 Ready
  • Overviews
  • Features
  • Design
  • Tech Specs
  • Download
  • FAQs

    • N301RT is a wireless router which complies with 802.11n standard and delivers up to 300Mbps wireless transmission rate. With two high performance antennas, N301RT ensures stable Wi-Fi signal and wide coverage, allowing multiple Wi-Fi devices to share Internet access simultaneously. Besides, it supports the most advanced WPA/WPA2 encryption method to prevent unauthorized access.

    Wireless N Speed
    N301RT complies with wireless 11n standard and delivers Wi-Fi speed up to 300Mbps, satisfying all internet activities like network  communication, online gaming and video streaming.


    Stable Performance
    With two high performance antennas, you are able to share stable Wi-Fi on different devices simultaneously.


    Enjoy Your IPTV
    Simply set up IPTV related information on N301RT's Easy Setup page, you can enjoy smooth IPTV and fast Wi-Fi at the same time.


    Easy Setup
    For Wi-Fi devices first connected to N301RT, the Log In page will show up automatically, configuration has never been so easier.



    Multiple Networks Available
    More than one Wi-Fi networks can be added to provide secure Wi-Fi access for guest sharing your home or office network.


    Advanced Security
    The most advanced WPA/WPA2 (TKIP/AES) encryption is provided to ensure the security of wireless connection without having to worry about unauthorized use.


    Parental Control
    Wi-Fi Schedule helps parents to set up time schedule for Wi-Fi network access, effectively preventing children caught in the Web, better for parental control.


    IPv6 Ready
    N301RT supports IPv6 protocol for higher security and wider IP address range.

    - Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
    - Up to 300Mbps data rate for Wi-Fi network.
    - Advanced MIMO technology enhances the throughput and wireless coverage.
    - Supports  DHCP, Static IP, PPPoE(dual access), PPTP(dual access), L2TP(dual access) broadband functions.
    - Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
    - Connects to secure network easily and fast using WPS.
    - Supports IP, Port, MAC, URL filtering and Port Forwarding.
    - QoS: Bandwidth Control based on IP/MAC.
    - Multi-SSID allows user to create multiple SSIDs according to their needs.
    - Supports VLAN function for IPTV and other internet services.
    - Universal repeater and WDS function for easy Wi-Fi extension.
    - Supports TR-069 protocol for remote centralized management.
    - SSH Server ensures the security of remote login.
    -  Easy setup simplifies the basic settings of the router.
    HARDWARE FEATURES
    Interface  4*10//100Mbps LAN Ports
      1*10/100Mbps WAN Port
    Power Supply  9V DC/0.5A
    Button  1 *RST/WPS Button, 1 *Power ON/OFF
    LED Indicators  1 *Power, 1 *CPU, 1 * Wireless, 1 *WAN, 4 *LAN
    Antenna  2*5dBi detachable antennas
    Dimensions (L x W x H)  6.0 x 3.7 x 0.9 In (152 x 94 x 24mm)
    WIRELESS FEATURES
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    RF Frequency  2.4~2.4835GHz
    Data Rate  802.11n: up to 300Mbps
      802.11g: up to 54Mbps (dynamic)
      802.11b: up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
    EIRP  < 20dBm
    Reception Sensitivity  270M: -61 dBm@10% PER
      135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    SOFTWARE FEATURES
    Operation Mode  Wireless ISP Client Router
      Wireless Client
      Repeater(Range Extender)
      Router
      Bridge with AP
      Client
    WAN Type  DHCP/Static IP/PPPoE(Dual access)/PPTP(Dual access) /L2TP(Dual access)
    IPv6 Network  WAN Setting, LAN Setting, RADVD for IPv6, IPv6 Tunnel to IPv4
    Wireless Functions  Multiple SSID, MAC Authentication, Universal Repeater, WDS,
      WPS, IPTV
    Schedule  Reboot Schedule, Wireless Schedule
    Firewall  SPI Firewall, MAC Filtering, IP Filtering, Port Filtering,
      URL Filtering, Port Forwarding, DMZ, NAT Mapping
    Management  QoS, TR-069 config, DDNS, DoS, Access Control, etc.
    Others  -
    Package Contents  N301RT Wireless Router *1
      Power Adapter *1
      Ethernet Cable *1
      Quick Installation Guide *1
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
