N300RG

300Mbps Wireless N Gigabit Router

  • - 300Mbps Wireless N Speed
    - Stable Wi-Fi Connection
    - Full Gigabit Wired Connections
    - Simple Remote Access with VPN
    - Multiple Wireless Network for Access Control
    - Flexible Bandwidth Management
    - Easy Setup
  • Overviews
  • Features
  • Design
  • Tech Specs
  • Download
  • FAQs

    • N300RG is a 300Mbps Wireless N Gigabit Router with three high gain fixed antennas. It enables you to connect high-speed wireless network with stable throughput. The full gigabit ports provide 10 times rate than normal 100Mbps solutions, which is the perfect choice to improve LAN communication speed. Since it provides Wireless Multibridge, WDS and VPN Server settings, N300RG can be also used as a VPN Server, a Repeater and a Wireless AP.


    300Mbps Wireless N Speed
    N300RG complies with wireless 11n standard and delivers Wi-Fi speed up to 300Mbps, satisfying all internet activities like network  communication,online gaming and video streaming.


    Stable Wi-Fi Connection
    Three high performance antennas ensure best signal stability and wide Wi-Fi range to eliminate dead zone.


    Full Gigabit Wired Connections
    One gigabit WAN port and four gigabit LAN ports offers 10x faster speed than fast Ethernet connections. Enjoy your ultrafast wired network.


    Simple Remote Access with VPN
    With VPN Sever supported, 5 PPTP Tunnels are provided to secure access to your home network, protecting your privacy and family safety while online.


    Multiple Wireless Network for Access Control
    More than one Wi-Fi networks can be added to provide secure Wi-Fi access for guest sharing your home or office network.


    Flexible Bandwidth Management
    Smart QoS is offered to assign bandwidth equally for each connected devices, making bandwidth control more easy and flexible.


    Easy Setup
    N300RG provides Internet Wizard and Wireless Wizard for you to setup the device step by step easily and fast.

    - Complies with IEEE 802.11n and IEEE 802.11g/b standards for 2.4GHz Wireless LAN.
    - Up to 300Mbps data rate for Wi-Fi network.
    - Advanced MIMO technology enhances the throughput and wireless coverage.
    - Five high performance gigabit Ethernet ports to achieve the most efficient data rate.
    - Supports PPPoE, DHCP and Static IP broadband functions.
    - Repeater function expands the wireless coverage and allows more terminals to access Internet.
    - Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
    - Connects to secure network easily and fast using WPS.
    - Multi-SSID allows user to create multiple LANs according to their needs.
    - The IP, MAC and URL filtering makes access and time control more flexibly.
    - The VPN server can not only protect the privacy of your information, but also simplify network management.
    - Smart QoS function can assign bandwidth to PCs equally by one click.
    HARDWARE FEATURES
    Interface  4 *10/100/1000Mbps LAN Ports
      1 *10/100/1000Mbps WAN Port
    Power Supply  5V DC/2.5A
    Button  1 *RST/WPS Button
      1 *Power ON/OFF Slide Switch
    LED Indicators  1 *Power, 1 *CPU, 1 *Wireless, 1 *WAN, 4 *LAN
    Antenna  3 *5dBi Fixed Antennas
    Dimensions (L x W x H)  7.2 x 5.3 x 1.0 In. (183.4 x 134.4 x 26mm)
    WIRELESS FEATURES
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    RF Frequency  2.4~2.4835GHz
    Data Rate  802. 11n: Up to 300Mbps
      802.11g: Up to 54Mbps (dynamic)
      802.11b: Up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
    EIRP  < 20dBm
    Reception Sensitivity  270M: -61 dBm@10% PER
      135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    SOFTWARE FEATURES
    Network  Internet Setup: PPPoE/DHCP/Static IP
      LAN/DHCP Setup: DHCP Server/DHCP Static Lease
    Wireless  Multiple BSS
      Multibridge(Repeater): Wireless Bridge/Wireless WAN
      MAC Authentication
      WDS
      WPS
    NAT/Routing   Port Forwarding
      DMZ/Twin IP
      Port Trigger
      Routing Table
    Firewall  Internet Access Control: IP/MAC Address filtering
      Net Detector
      Remote/Internal access list
    Utility  VPN Server, DDNS, WOL, Host Scan
    Traffic   QoS Setup, Connection Control, Wired Port Setup
    Management  System Log
      Administrator Setup
      Firmware Upgrade
      System Time
      Configuration backup/restore
    Package Contents  N300RG Wireless Router *1
      Power Adapter *1
      Ethernet Cable *1
      Quick Installation Guide *1
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
