N3GR

150Mbps 3G Wireless N Router

  • - 3G Mobile Broadband Internet Connection
    - Outstanding 3G Card Compatibility
    - Robust Security




  • N3GR is a 3G Wireless N Router. It allows users to set up a 150Mbps wireless network quickly and share a 3G mobile connection. By connecting to a UMTS/HSPA/EVDO USB card, this router will instantly establish a Wi-Fi hotspot which can make you share an Internet connection wherever 3G is available. So no matter where you are, on the train, on camping or at a construction site, you'll get a reliable wireless connection to accommodate your networking needs.



    3G Mobile Broadband Internet Connection
    The router features with one USB 2.0 port for inserting a compatible mobile broadband USB modem, by which you can easily access 3G mobile broadband and share network connection with others. Even better, it allows users to access Internet by DSL/cable or an existing wireless hotspot, keeping users online while one connection fails.



    Outstanding 3G Card Compatibility
    Compatible with most of Telecom, Unicom and Mobile 3G network cards, N3GR can effectively meet various of users needs to access and share 3G mobile broadband. The excellent quality and compatibility provide users with stable and reliable wireless connection experience.



    Robust Security
    The most advanced WPA/WPA2 (TKIP/AES) encryption is provided to ensure the security of wireless connection. Only the users who known the SSID and encryption key can connect to the network, so that users needn’t worry about being occupied by others. What’s more, to keep the Internet browsing experience safe, it provides IP/Port/MAC filter to strengthen the security outside and inside the network

    - Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
    - Compatible with UMTS/HSPA/EVDO USB modem.
    - Supports PPPoE, DHCP and Static IP broadband functions.
    - Provides one USB 2.0 port for 3G USB modem connection.
    - Supports 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
    - The IP, MAC and Port filtering makes access and time control more flexibly.
    - Bridge and Repeater modes can expand the wireless coverage and allow more PCs to access Internet.
    - QoS function allocates network bandwidth reasonably.
    - WiFI ON and WiFi reboot schedule for better management.
    HARDWARE FEATURES
    Interface  4*10/100Mbps LAN Ports
      1*10/100Mbps WAN Port
      1*USB 2.0 port
    Power Supply  9V DC/0.8A
    Button  Reset Button
    LED Indicators  1*Power, 1*CPU, 1*Wireless, 1*WAN, 4*LAN, 1*3G
    Dimensions  133mm x 96.7mm x 24.2mm (L x W x H )
    Antenna  1*5dBi detachable antenna
    Environment  Operating Temperature: 0℃~40℃ (32℉~104℉)
      Storage Temperature: -40~70℃ (-40℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~95% non-condensing
    WIRELESS FEATURES
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    RF Frequency  2.4~2.4835GHz
    Data Rate  802.11n: up to 150Mbps
      802.11g: up to 54Mbps (dynamic)
      802.11b: up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2 (AES/TKIP)
    Output Power  20dBm (Max.)
    Channels  1-11 (North America), 1-13 (General Europe), 1-14 (Japan)
    Modulation Type  DBPSK, DQPSK, CCK and OFDM (BPSK,QPSK,16-QAM/ 64-QAM)
    Reception Sensitivity  135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    SOFTWARE FEATURES
    Easy Setup  Internet/ Wireless setting, 3G backup Setting
    Network  WAN: DHCP/Static IP/PPPoE/L2TP/PPTP/3G
      LAN Setting
      Static DHCP Setting
    Wireless  Wireless Status
      Basic Setting
      MAC Authentication
      WPS
      Bridge Setting: Repeater Bridge/Repeater WAN/WDS mode
      Advanced Setting
    Firewall  System Firewall
      IP/Port Filtering
      MAC Filter
      URL Filter
      Port Forwarding
      DMZ Setting
    Management  Traffic Statistics
      DDNS
      NTP Setting
      Remote Management
      System Log
      Upgrade Firmware
      Administrator Setting
      Schedule
