ND150

150Mbps Wireless N ADSL 2/2+ Modem Router

  • - All-in-one Solution
    - 150Mbps Wireless N Speed
    - Selectable ADSL or WAN Broadband Access
    - One-click Wi-Fi On/Off
    - Multiple Networks Available
    - IPv6 Ready
    - Advanced Security
    - Easy Setup
  • ND150 is a Wireless ADSL Router which integrates the functions of high speed ADSL Modem, wireless router and 4-port switch into one. Complied with advanced IEEE 802.11n and latest ADSL 2/2+ standards, it delivers up to 150Mbps wireless data rate and provide higher performance with wider transmission coverage. Besides, ADSL or WAN connection is selectable accordingly.




    All-in-one Solution
    ND150 is a all-in-one solution that can be used as a high speed ADSL modem, Wireless Router, Access Point and 4-port Switch, clean up your desktop.


    150Mbps Wireless N Speed
    With 802.11n compliant, you will enjoy 150Mbps Wi-Fi for fast and stable Wireless network connection.


    Selectable ADSL or WAN Broadband Access
    With one ADSL port and one WAN port, Both ADSL or WAN broadband connection are selectable for you to access the Internet.


    One-click Wi-Fi On/Off
    Quickly turn Wi-Fi on or off by pressing the Wi-Fi on/off button on the router, which helps to simplify configuration and save power.


    Multiple Networks Available
    More than one Wi-Fi networks can be added to provide secure Wi-Fi access for guest sharing your home or office network.


    IPv6 Ready
    ND150 supports IPv6 protocol and back compatible with IPv4, safer and more practical.


    Advanced Security
    The most advanced WPA/WPA2 (TKIP/AES) encryption is provided to secure Wi-Fi connection and avoid any unauthorized use.


    Easy Setup
    Simply follow the Easy Setup's configuration step-by-step, you are able to access the Internet quickly and build Wi-Fi network easily.



    - Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
    - Up to 150Mbps data rate for Wi-Fi network.
    - Combines functions of high speed ADSL Modem, wireless router and 4-port switch.
    - Supports both ADSL and WAN broadband access.
    - Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
    - Supports IPv6 protocol.
    - Supports PVC detecting automatically.
    - IGMP multicast and IGMP proxy are supported.
    - Multiple BSSID function allows user to set maximum three virtual  APs for different needs.
    - QoS function allocates network bandwidth reasonably.
    - The IP, MAC and URL filtering makes access and time control more flexibly.
    - Repeater and WDS function for easy WiFi expansion.
    - Wi-Fi on/off and Power on/off buttons make configuration simple.

    HARDWARE FEATURES
    Interface  3 *10/100Mbps RJ45 LAN Ports
      1 *10/100Mbps RJ45 WAN/LAN Port
      1 *RJ11 ADSL Port
    Power Supply  9V DC/0.5A
    Button  WPS/RST Button
      Wi-Fi ON/OFF Button
      Power ON/OFF Switch
    LED Indicators  1 *Power, 1 *System, 1*Internet, 1*WLAN, 1*ADSL, 4 *LAN
    Antenna  1*5dBi Fixed Antenna
    Dimensions (L x W x H)  4.8 x 3.9 x 2.1 in. (122 x 99 x 55mm)
    WIRELESS FEATURES
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
      ADSL, ADSL2, ADSL2+
    RF Frequency  2.4~2.4835GHz
    Data Rate  802.11n: up to 150Mbps
      802.11g: up to 54Mbps (dynamic)
      802.11b: up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2 (AES/TKIP)
    EIRP  < 20dbm
    Reception Sensitivity  135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    SOFTWARE FEATURES
    Network  Easy Setup
      WAN
      LAN, LAN IPv6, DHCP
    Wireless  MBSSID, Access Control List
      WPS, WDS, Repeater
    Advance  Route, NAT, QoS, CWMP
      Port Mapping, Bridge Setting
    Service  IGMP, UPnP, DDNS, FTP Server
    Firewall  MAC/IP/PORT /URL Filter
      ACL, DoS
    Maintenance  Upgrade, Password, Reboot
      Time, Log, Diagnostics
    Others
    Package Contents  ND150 Wireless ADSL Router *1
      Power Adapter *1
      Ethernet Cable *1
      Telephone Cable *2
      ADSL Splitter *1
      Quick Installation Guide *1
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
