- Delivers speeds up to 1200Mbps (5GHz 867Mbps + 2.4GHz 300Mbps).
- Complies with the 802.11ac Wi-Fi standard- 802.3af/at compliant PoE for simple deployment and low cost.
- Handles up to 128 Wi-Fi connections simultaneously.
- Two options, local device management and remote AC central control, are available.-
- Provides 64/128-bit WEP, WPA, and WPA2.
- Supports Multiple SSIDs, WDS, Universal Repeater, and Wireless Scheduler
| Hardware | |
|---|---|
| Interface | - 1 *1000Mbps PoE port (Auto MDI/MDIX) |
| Button | - 1 *RST button |
| Power Supply | - IEEE 802.3af/at compliant PoE |
| LED Indicator | - 1 * SYSTEM LED (three colors) |
| Antenna |
- 4 * internal antennas
|
| Dimensions (D x H) | - 9.6 x 2.2 in. (245 x 55 mm) |
| Wireless | |
|---|---|
| Standards | - IEEE 802.11ac, IEEE 802.11a IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| RF Frequency | - 2.4GHz/5GHz |
| Data Rate |
- 5GHz: 867Mbps - 2.4GHz: 300Mbps |
| EIRP |
- 2.4GHz < 20dBm
- 5GHz < 20dBm
|
| Wireless Security | - 64/128-bit WEP, WPA, and WPA2 |
| Reception Sensitivity |
- 2.4G: 11b: < -81dBm
11g: -68dBm
11n: HT20 < -65dBm, HT40 < -62dBm
- 5G: 11a: -68dBm
11ac: -51dBm
11n: HT20 < -65dBm, HT40 < -62dBm
|
| Software | |
|---|---|
|
Status
|
- System Status
|
| Network | - LAN Settings |
| Operation Mode |
- Bridge Mode
|
| Wireless |
- Basic Settings
|
| Management |
- Administrator Setting
- Time Setting
- Upgrade Firmware
- System Configuration
- System Log
- Reboot Schedule
- Logout
|
| Others | |
|---|---|
| Package Contents |
- AC1200 Wireless Dual Band Ceiling Mount AP * 1
- Quick Installation Guide * 1
|
| Environment |
- Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)
- Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
- Operating Humidity: 5%~95% non-condensing
- Storage Humidity: 5%~95% non-condensing
|
