CA600-PoE

600Mbps Wireless Ceiling Mount AP

  • - 600Mbps 11N Ultra-fast Wi-Fi
    - 4T4R MIMO Technology
    - IEEE 802.3af/at Compliant PoE
    - Wide Wi-Fi Coverage
    - Flexible Management Options
    - Concurrent Multiple SSIDs



  • - Delivers speeds up to 600Mbps- Complies with the 802.11n Wi-Fi standard.

    - Adopts the 4T4R MIMO technology.

    - 802.3af/at compliant PoE for simple deployment and low cost- Handles up to 32 Wi-Fi connections simultaneously.

    - Two options, local device management and remote AC central control, are available.

    - Provides 64/128-bit WEP, WPA, and WPA2.

    - Supports Multiple SSIDs, WDS, Universal Repeater, and Wireless Scheduler

    Hardware
    Interface  - 1 *100BaseTX (Auto MDI/MDIX) LAN/PoE Port
    Button  - 1 *RST button
    Power Supply  - IEEE 802.3af/at PoE Power Supply
    LED Indicator  - 1 * SYSTEM LED  (three colors)
    Antenna
    - 4 * internal antennas
    Dimensions (D x H)  - 7.9 x 1.4 in. (200 x 35 mm)
    Wireless
    Standards  - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
    RF Frequency  - 2.4~2.4835GHz
    Data Rate
    - 802. 11n: up to 300Mbps
    - 802.11g: up to 54Mbps
    - 802.11b: up to11Mbps
    EIRP  - < 20dBm
    Wireless Security  - 64/128-bit WEP, WPA, and WPA2
    Reception Sensitivity
    - 11b: < -81dBm
    - 11g: < -68dBm
    - 11n: HT20 < -65dBm         HT40 < -62dBm
    Wireless
    Standards  - IEEE 802.11ac, IEEE 802.11a IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
    RF Frequency  - 2.4GHz/5GHz
    Data Rate  - 5GHz: 433Mbps
    - 2.4GHz: 300Mbps
    EIRP  - < 27dBm
    Wireless Security  - 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
    Reception Sensitivity
    - 2.4G: 11b:<-79dbm;
               11g:<-68dbm;
               11n: HT20<-65dbm  HT40:<-61dbm
    - 5G:  11a:<-68dbm
             11ac: HT20<-65dbm  HT40:<-61dbm  HT80:<-51dbm
    Others
    Package Contents
    - CA600-POE Wireless Ceiling Mount AP*1
    - Ethernet Cable *1
    - Quick Installation Guide *1
    Environment
    - Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)
    - Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
    - Operating Humidity: 5%~95% non-condensing
    - Storage Humidity: 5%~95% non-condensing
