A008 KIT is a 2.4G high gain Omni-directional antenna which is designed to largely extend signal coverage and deliver better wireless performance for users. It is mainly used in wireless Adapter and wireless Router/AP whose antenna is detachable. You can get stronger wireless signal simply by replacing your existing Wi-Fi antenna with A008 KIT.
- Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
- 8dBi high gain makes your signal coverage much wider.
- Provides RP-SMA female connector.
- Very easy to install, no configuration required.
|
HARDWARE FEATURES |
|
RF Frequency |
2.4GHz |
|
Impedance |
50 Ohms |
|
VSWR |
1.92:1 (Max.) |
|
Gain |
8 ±1dBi |
|
Polarization |
Linear, Vertical |
|
Radiation |
Omni-directional |
|
Connector Type |
RP-SMA |
|
Application |
- Indoor & Outdoor |
|
Color |
White |
|
Operation Temperature |
20℃~70℃ (-4℉~158℉) |
|
Storage Temperature |
30℃~80℃ (-22 ℉ ~176℉) |
