S808V

8-Port 10/100Mbps PoE Switch








  • Overviews
  • Features
  • Design
  • Tech Specs
  • Download
  • FAQs
    •
    - Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af standards.
    - Two ports support PoE Power up to 15.4 Watts.
    - IEEE802.3x flow control for full duplex operation.
    - Supports store and forward switching scheme capability.
    - Supports auto MDI/MDIX for each port.
    HARDWARE FEATURES
    Standards  IEEE 802.3, IEEE 802.3u, IEEE 802.3x, 802.3af
    Interface  8*10/100Mbps Auto-negotiating, Auto  MDI-MDI/X ports
    LED  Power, Link/Activity, Speed
    Dimension  135.00 * 77.32 * 24.00mm (L* W * H)
    Backup Bandwidth  1.6Gbps
    MAC Address Learning  Auto-learning, auto update
    Transfer Method  Store and Forward
    Power Requirements  9V/500mA
    Network Cables  UTP Cat 5 cable or higher
    Environment  Operating Temperature: 0℃~40℃ (32℉~104℉)
      Storage Temperature: -40~70℃ (-40℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~95% non-condensing
