N150UH

150Mbps Long Range Wireless N USB Ada

  • - Long Distance Wi-Fi Connectivity
    - One Click Wi-Fi Protected Setup





  • N150UH is a Long Range Wireless USB Adapter which is designed for long distance reliable Wi-Fi connection. It complies with IEEE 802.11n standard and can deliver up to 150Mbps wireless data rate. N150UH supports advanced WPA/WPA2 encryption and WPS (Wi-Fi Protected Setup) with fast-click button for high security.





    Long Distance Wi-Fi Connectivity

     The high output power and long range design allows you to create a stable wireless connection to long distance WLAN network. Especially the high gain antenna can be revolved and adjusted in different directions to get better Wi-Fi signal.



    One Click Wi-Fi Protected Setup

    To secure the wireless connection, the adapter provides a WPS button so that users can easily setup a wireless connection with protection just by one click.

    - Complies with IEEE 802.11n /g/b standards for 2.4GHz Wireless LAN.

    - Up to 150Mbps data rate for Wi-Fi network.

    - Long range disign is the best solution for long distance transfer.

    - Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK (TKIP/AES) encryption.

    - WPS button allows to setup a security connection by one click.

    - Supports infrastructure and Ad-Hoc network modes.

    - Supports Windows 10/8/7/ XP/Vista (32/64-bit) and Mac OS.

    - Easy to install and configure.

    HARDWARE FEATURES
    Interface  USB 2.0
    Button  1 *WPS Button
    LED Indicator  1 *Status
    Antenna  1 *5dBi detachable antenna
    WIRELESS FEATURES
    Standards  IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
    RF Frequency  2.4~2.4835GHz
    Data Rate  802. 11n: Up to 150Mbps
      802.11g: Up to 54Mbps (dynamic)
      802.11b: Up to11Mbps (dynamic)
    Wireless Security  64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
    EIRP  <20dBm
    Reception Sensitivity  135M: -65 dBm@10% PER
      54M: -68 dBm@10% PER
      11M: -85 dBm@8% PER
      6M: -88 dBm@10% PER
      1M: -90 dBm@8% PER
    Others
    Package Contents  N150UH Wireless Adapter *1
      5dBi antenna *1
      Resource CD *1
      1.5m USB 2.0 extension cable with cradle *1
      Quick Installation Guide *1
    System Requirement  Windows 10 (32/64bits), Windows 8 (32/64bits),Windows 7 (32/64bits), Windows XP (32/64bits)
      Mac OS X 10.3~10.6
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
