- Complies with IEEE 802.11n/g/b standards for 2.4GHz Wireless LAN.
- Up to 300Mbps data rate for Wi-Fi network.
- Supports DHCP, Static IP, PPPoE(dual access), PPTP(dual access), L2TP(dual access) broadband functions.
- Advanced security encryptions include 64/128-bit WEP, WPA, WPA2 and WPA-Mixed help to secure wireless communications.
- Connects to secure network easily and fast using WPS.
- Supports IP, Port, MAC, URL filtering and Port Forwarding.
- QoS and WMM features gives priorities to bandwidth-intensive applications like HD streaming and gaming
- Multi-SSID allows user to create multiple SSIDs according to their needs.
- Universal repeater and WDS function for easy Wi-Fi extension.
- Wireless timer switch to enjoy healthy life.With wireless timing functionaccording set the time to automatically turn on or turn off the wireless network, , saving energy while allowing families to enjoy a healthy home environment.
- Easy setup with smartphone UI simplifies the basic settings
| HARDWARE FEATURES | |
|---|---|
| Interface | 2 *10/100Mbps LAN Ports |
| 1 *10/100Mbps WAN Port | |
| Power Supply | Power Supply |
| Antenna | 2 *5dBi fixed antennas |
| Button | 1 *RST/WPS Button |
| LED Indicators | 1 *CPU, 1 *Wireless |
| Dimensions(L x W x H) | 3.6 x 3.1 x 1.0 in. ( 91 x 80 x 25 mm) |
| WIRELESS FEATURES | |
|---|---|
| Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| RF Frequency | 2.4000~2.4835GHz |
| Data Rate | 802. 11n: Up to 300Mbps |
| 802.11g: Up to 54Mbps (dynamic) | |
| 802.11b: Up to11Mbps (dynamic) | |
| EIRP | < 20dBm |
| Wireless Security | 64/128-bit WEP, WPA/WPA2 and WPA-Mixed |
| Reception Sensitivity | 270M: -61 dBm@10% PER |
| 135M: -65 dBm@10% PER | |
| 54M: -68 dBm@10% PER | |
| 11M: -85 dBm@8% PER | |
| 6M: -88 dBm@10% PER | |
| 1M: -90 dBm@8% PER | |
| SOFTWARE FEATURES | |
|---|---|
| Operation Mode | Gateway Mode |
| Bridge Mode | |
| Repeater Mode | |
| WISP Mode | |
| Network | WAN Setting |
| LAN Setting | |
| Static DHCP Setting | |
| WAN Type | DHCP/Static IP/PPPoE/PPTP /L2TP |
| Wireless Functions | Multiple Aps, MAC Authentication, WDS, WPS,WMM |
| Schedule | Reboot Schedule, Wireless Schedule |
| Firewall | MAC Filtering, IP Filtering, Port Filtering, URL Filtering, Port Forwarding, DMZ |
| Management | Firmware Upgrade, QoS, DDNS, Access Control,UPnP |
| - | - |
| Others | - |
| Package Contents | N200RE Wireless Router *1 |
| Power Adapter *1 | |
| Ethernet Cable *1 | |
| Quick Installation Guide *1 | |
| Environment | Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) |
| Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
