P100

10/100Mbps Fast Ethernet Desktop PCI Adapter








  • - Complies with IEEE 802.3/802.3u standards.

    - Supports 10/100Mbps Ethernet transmission rate.

    - Two LED indicators for easy diagnostic.

    - Supports plug-and-play, no driver required.

    - Supports Full & Half Duplex flow control.

    - Supports transmission/receiving FIFO.

    - Supports Windows XP/Vista/7, Linux and Mac OS.

    HARDWARE FEATURES
    Standards  IEEE 802.3, IEEE 802.3u
    Port  1*10/100Mbps RJ45 port
    Transmission Rate  10/100Mbps for Full/Half-Duplex modes
    Network Interface  PCI
    LED Indicator  1 *LINK/ACT
    Package Contents  P100 Network Adapter *1
      TOTOLINK Flyer
    System Requiremen  Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP (32/64bits)
      Linux
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing

    All content on this website is only applicable to models selling in overseas markets (outside China mainland, Taiwan and South Korea), any model purchased from China mainland, Taiwan or South Korea caused damage by upgrading software on this website is excluded in after-sales service range.

    Datasheet

    Model Download Version Updated
    P100 P100_datasheet_v2.0.pdf Ver2.0 2015-12-26







    Model Download Version Updated
    P100 P100_Photo002.jpg Resolution 600x600 2014-03-19
    P100 P100_Photo001.jpg Resolution 600x600 2014-03-19
